Central Lithium batteries are designed with high efficiency charging & discharging with more than 6000 times cycle life to ensure uninterrupted & longer life span. .
| Model | CB51.2V/100AH | CB51.2V/200AH | CB51.2V/280AH |
|---|---|---|---|
| Nominal Voltage | 51.2V | 51.2V | 51.2V |
| Nominal Capacity | 100Ah | 200Ah | 280Ah |
| Nominal Energy | 5.12kw | 10.24kw | 14.33kw |
| Charge Voltage | 58.4V | 58.4V | 58.4V |
| Standard Charging Current | 20A | 40A | 50A |
| Max. Continuous Charging Current | 100A | 100A | 100A |
| Standard Discharge Current | 20A | 40A | 50A |
| Continuous Discharge Current | 100A | 100A | 100A |
| Peak Discharge Current | 200A (3S) | 200A (3S) | 200A (3S) |
| Discharge Cut-off Voltage | 42V | 42V | 42V |
| Charge Temperature Range | 0~60°C | 0~60°C | 0~60°C |
| Discharge Temperature Range | -10~65°C | -10~65°C | -10~65°C |
| Storage Temperature Range | -5~40°C | -5~40°C | -5~40°C |
| Storage Humidity | 65±20%HR | 65±20%HR | 65±20%HR |
| Size (L×W×H) | 630×440×176mm | 760×450×207mm | 580×750×279mm |
| Package Size (L×W×H) | 690×525×240mm | 830×525×425mm | 750×910×495mm |
| Net Weight | 44kg | 89kg | 113kg |
| Gross Weight | 46kg | 102kg | 128kg |
| Cycle Life | >6000 times | >6000 times | >6000 times |
| SOC Indication | LED Lights LCD Screen | LED Lights LCD Screen | LED Lights LCD Screen |
| Communication Protocol | RS232/RS485/CAN | RS232/RS485/CAN | RS232/RS485/CAN |
